LE3U PLC FX3U PLC

• Support Mitsubishi GX-Develoer\GX-WORK2
• Support for human-machine interface connection, the application is completely equivalent to Mitsubishi FX3U
• Support ladder programming, download, monitoring.
• The programming port used for program download and communication with the human machine
• This PLC adopts an industrial-grade 32-bit MCU with strong anti-interference, and its running speed far exceeds that of FX3U.
• This PLC transmission baud rate is 38400

LE3U PLC WIRE

LE3U Cell

LE3U FAQ

1. DC+ 24V power supply input positive pole
2. DC- 24V power supply input negative pole
3. Com Input common, low level
4.What is ” JO” CAL & CAH ?
CAN function is temporarily not supported
5.The working principle of RS485 communication is as follows:
Our le3u series PLC support MODBUS-RTU

LE3U PLC Upload and Download
